| Loại Transceiver |
SFP |
| Media Type |
Single-Mode Fiber (SMF) |
| TX Wavelength |
1310 nm |
| RX Wavelength |
1310 nm |
| Minimum Optical Budget |
13 dB |
| Maximum Distance |
10km |
| Supported Data Rate |
1.063-1.25 Gbps |
| Supported Applications |
Gigabit Ethernet (1.25 Gbps), 1G Fiber Channel (1.0625 Gbps) |
| DDM/DOM |
Support |
| Temperature Range |
Standard 0°-70°C |
| Connectors |
Double LC |
| TX Wavelength Bandwidth |
100 nm (1260-1360 nm) |
| RX Wavelength Bandwidth |
100 nm (1260-1360 nm) |
| Minimum Transmitting Power |
-9 dB |
| Maximum Transmitting Power |
3 dB |
| Receiver Sensitivity |
-22 dBm |
| Receiver Overload |
-3 dBm |
| Dispersion |
70-100 ps/nm |
| Transmitter Type |
FP Laser |
| Receiver Type |
PIN photodiode |
| Power |
+3.3V single power supply |
| Chipset |
MAXIM, MINDSPEED, SEMTECH |
| Compliance |
CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8074i, RoHS, SFP MSA |
